Specifications

• Number of Conductors: 2 Pin
• Mounting Type: Cord
• Gender: Male
• Locking: Button Locking
• Handle Material: Thermoplastic
• Packaging Type: Bulk
• Standard Connector Type: Speaker Connector
• Operating Temperature: -30℃ to +80

Electrical

• Rated Current/Voltage: 30A  / 250VAC
• Contact Resistance: ≤10mΩ
• Insulation Resistance: ≥2GΩ
• Withstanding Voltage: 1500VDC

Mechanical

• Insertion/Extraction Force: 10~30N
• Life Cycle: 1000 Cycles
• Coupling Locking Style: Button Latch
